Water Milk Analog Magnetic Flow Meter Price Electromagnetic Flowmeter

Water Milk Analog Magnetic Flow Meter Price Electromagnetic Flowmeter

Inquire Now None

Product details

Quick Details:

Place of Origin	Henan, China (Mainland)	Brand Name	WEILI	Model Number	MGG
Product Name	MGG	Medium	Corrosive	Accuracy	0.5%
Power supply	220VAC/ 24VDC	Output	4-20mA /RS485	Application	Measuring Liquids
Connection	Thread	Material	Stainless Steel	Type	Integral

Product Description:

Magne W3000 PLUS Sanitary Centrifugal type Electromagnetic flowmeter adopting new sanitary centrifugal liner and technology ,which is in line with the food industry hygiene requirements , At the same time, its stainless steel shell connected with stainless steel clamp ,easy to remove and clean , so that the flowmeter can not easily be contaminated in using process and applied in food manufacture processing of Mineral water, soy sauce, jam, beer, fruit juice, rice, milk ,etc and Health and chemical industry .


Nominal Bore	DN10～DN300mm
Nominal Pressure	1.0～4.0MPa
Accuracy	±0.5%；±0.3%
Flow range	0～10m/s(Flow Velocity)
Liner materia	PFA
Measuring Electrodes	316L Stainless steel , Harrington alloy B/C, Titanium , Tantalum
Shell material	Stainless steel
Medium temperature	Remote type-10℃ ~+160℃ ,Integral type -10℃ ～ +80℃
Connection Mode	ISO Standard Quick Connector

Main Features:

1) It adopting new sanitary centrifugal liner,that prevent the residue of measured media accumulated in the measuring pipe .

2) It used Fast Connection program and makes the demolition of the electromagnetic flowmeter, maintenance and cleaning to be facilitated.

3)It uses 16 digit embedded Super-Micro power consumption Microprocessor ,meanwhile adopts special technical designing excitation system of sensor ,having the functions such as higher integration ,fast in operational speed ,stable accuracy in calculation ,digital signal processing ,strong capability of interference immunity ,stable and reliable measurement.

4)The flowmeter is a two-way measurement system with three totalizers: positive total, reverse total and total difference; can display positive and negative flow, and has multiple outputs: current, pulse, digital communication, HART protocol.
